TECHNICAL SPECIFICATIONS
Installation type: Vanity, Wall-hung
Material: Vitreous china
Net weight (kg): 21.9
Option: without tap hole
Taphole configuration: No tapholes
TECHNICAL DESCRIPTION
Cutable countertop basin LAUFEN LIVING SQUARE, sanitary ceramic, EN 14688, dimensions 900 x 480 mm, angular, 1 centre tap hole, Special feature: overflow channel glazed, cutable to 650 mm, with towel, rail cutable to 865 mm, integreated shelves, Further options / accessories: Surface refinement LCC (only white), 3 tap holes, without tap holes, with or without overflow, hole for soap dispenser, left or right, electronic valve unit to control water temperature and, flow rate, 3 tap holes distance 8 inches with overflow, towel rail 38143.3, furniture, Order no. 81643.3
MOUNTING ACCESORIES EXCLUDED
2x Mounting set M10 x 140 mm, order no. 89988.2
TECHNICAL DOCUMENTS
Download the CAD (2D, 3D) files of this product in different formats. | ⚠ Caution: CAD files should not be used for computer-controlled (CNC) cutting of countertops or similar and are for space-planning & room rendering purposes only. Upon request cut-out templates are available from Laufen. All drawings contain the necessary measurements (mm) which are subject to standard tolerances. Exact measurements, in particular for customized installation scenarios, can only be taken from the finished product.
LIVING
living city: A system with corners and edges, yet so flexible and easy to maintain. living city has a clear concept and clear forms. Thanks to the modular system, washbasins with and without storage are available in many widths. Reduction, not stone cold sobriety, individualism without idiosyncrasy: The language of the living city forms is aimed at people who live in modern surroundings and create a living environment with refined awareness and sensitivity to materials. The design of LAUFEN rectangular wall-hung WCs and bidets suits this context perfectly.
