TECHNICAL SPECIFICATIONS
Bowl position: Left, Right
Double basin
Fixing kit: Not included
Installation type: Vanity, Wall-hung
Integrated shelf
Internal Shape: 4 - Oval
Material: Saphirkeramik
Net weight (kg): 24.4
Number of fixing points: 4
Option: one tap hole, centre
Overflow type: Standard
Shape: Soft
Taphole configuration: 1 taphole in the middle
Waste: Not included
TECHNICAL DESCRIPTION
Double countertop basin Laufen INO, Saphirkeramik, EN 31, dimensions 1420 x 450 mm, per basin 1 centre tap hole.
Special feature: overflow channel glazed.
Further options / accessories: Surface refinement LCC (only white), without tap holes, per basin 1 centre tap hole and without overflow, without tap hole and overflow, bathtubs, furniture.
MOUNTING ACCESORIES EXCLUDED
2x Mounting set M10 x 140 mm, order no. H899882
TECHNICAL DOCUMENTS
Download the CAD (2D, 3D) files of this product in different formats. | ⚠ Caution: CAD files should not be used for computer-controlled (CNC) cutting of countertops or similar and are for space-planning & room rendering purposes only. Upon request cut-out templates are available from LAUFEN. All drawings contain the necessary measurements (mm) which are subject to standard tolerances. Exact measurements, in particular for customized installation scenarios, can only be taken from the finished product.
INO
The new bathroom collection Ino, designed for LAUFEN by French designer Toan Nguyen, understands itself as a fresh interpretation of classic washbasin forms. The innovative collection skilfully uses the creative possibilities of LAUFEN’s Saphirkeramik. Elegant, inviting and almost weightless objects, the pieces work with simple lines, creating soft yet extremely stable walls. The collection includes a wall-mounted washbasin, a countertop or half inserted washbasin bowl, as well as high-quality bathroom furniture and two bathtubs.
